Top-Notch PVC Fast Door with Fire-retardant & Pinch-Preventive Properties

Short Description:

The stacking system of the Wind-Resistant Stacking High Speed Door provides a more efficient and smoother lifting function, making it ideal for frequent use in busy environments. The system also saves space, as the curtain can be folded neatly on top of each other, creating a compact stack that ensures the maximum opening width is retained, providing easy access for forklifts and other equipment.


Product Detail

Product Tags

Product Detail

Product name Wind-Resistant Stacking High Speed Door
Max Size W11000 x H7000mm ( interior )

W10000 x H6000mm ( exterior )

Curtain Quality PVC 1.0 mm thickness
With galvanized steel windproof strip
System Quality Motor/Germany SEW Motor
380V or 220V/, 0.75KW ~ 1.5KW
Speed 0.7m/s-1.1m/s, 2000 times a day
Opening Double-side radar / Infrared sensors
Cover box Stainless steel ( 201SS / 304SS )

or Galvanized steel box

Switch Manual rocker, Wall Emergency switch

Features

"Windproof" high speed stacking doors use folding high speed lifting, built in transverse wind bar design, so that wind pressure are spread to the whole curtain. Has good wind resistance performance, but also has a variety of roller type high speed roll doors advantages. Suitable for all kinds of buildings with large area and long span with wind pressure or negative pressure of 65 kg/㎡. High demand frequent logistics of various types of building exterior wall specialized use the fast door.

FAQ

1. Can I get a sample to check your quality?
Re: Sample panel is available.

2. How can I know the price exactly?
Re: Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.

3. Is it difficult to install your door?
Re: Easy to install. We have manual book and installation video for your reference. We also provide support for training your staff in our factory.
